High Speed Mulching Film Punching Machine

High Speed Mulching Film Punching Machine

High speed Mulching Film Punching Machine, Easy operating, Intelligent and Efficient, Hole spacing and Hold diameter are freely adjustable. hole spacing and aperture are freely adjustable, with Waste recycling.

Machine Characteristics & Technical Parameters

  1. Punching form: double servo synchronous material feeding, follow -up punching.
  2. Width range of mulch film : 400-2000mm.
  3. Punching speed:40-120m/minute.
  4. Hole distance range/film width:50-1500mmif hole diameter smaller than 2mm.it will be calculated according to the mold.

  5. Plant spacing range: 50-2000mm (if hole diameter is smaller than 2mm, it will be calculated according to the mold.)

  6. Hole diameter:  1~100mm , Optional.

  7. Puncher holding frame: Aluminum frame.

  8. Table device: fixed platform, the height of 4feet can be adjusted freely.

  9. Punching motor: INVT servo motor.

  10. Follow -up motor: INVT servo motor.

  11. Follow -up punching structure: type of double servo motor follow -up.

  12. Waste recycling structure: conveyor belt transmission, negative pressure fan suction double bucket recycling.
